Beskrivelse og data
Measuring range |
|
|---|---|
CO2 |
(infrared) 0 … 20 % |
O2 |
0 … 21 % |
NO |
0 … 5.000 ppm |
NO2 |
0 … 1.000 ppm |
SO2 |
0 … 5.000 ppm |
H2S |
0 … 2.000 ppm |
CO (H2 compensated) |
0 … 10.000 ppm |
Differential pressure |
± 100 hPa |
Fluegas temperature |
0 … 1.100°C; with suitable probe |
Dimensions and other data |
|
|---|---|
Data storage |
internally as well as on SD-card |
Data transfer |
via Bluetooth (option) or USB-cable |
Display |
3,5″ colour-TFT |
Flow velocity |
1 … 100 m/s |
Combustion air temperature |
K-type standard (option) |
Battery operating time |
up to 15 hours non-stop operation with lithium ion battery |
Weight |
approx. 750 g |
Dimensions |
110 x 225 x 52 mm |
